Mercedes-Benz GLC OEM Integrated Backup Camera System

The FMC-GLC systems package is a high definition rear view camera and video integration module for your vehicle with or without Navigation. The video interface connects through a simple plug and play OEM Integrated LVDS connection to the factory screen. The FMC-GLC Interface Module has a dedicated rear view camera input that will automatically trigger when in reverse and revert back when in park or drive all using your OEM screen to display the backup camera feed. Along with a dedicated rear camera input, the FMC-GLC system also has 3 additional AV inputs should you decide to add a front camera (manual trigger or automatic trigger), DVD Player, TV Tuner or any external video source with AV inputs. This system is an OEM integration package that maintains your factory set up while upgrading your vehicle with full Multimedia Video Integration. Once installed, the system is ready for use without any dealer activation or coding required.

System Highlight Notes*

• • 2013 + Video Interface Module contains NBT (Dynamic Parking Lines) – Parking Assistance System

Mercedes-Benz GLC Systems Compatibility

Mercedes-Benz GLC Interface Module Features

Input

• • Plug & Play installation by LVDS cable
  • Connected devices controlled by iDrive buttons
  • DVD & NAVI control by through optional touch screen panel
  • 1 x dedicated Rear-View Camera input
  • 3 x A/V Inputs
  • 1 x LCD input

Output

• • 2 x CVBS output (video out for headrest monitor installation)
  • 1 x Audio output
  • 1 x LCD output
  • Factory button function & provided remote control

Power

• • Input power : 8V DC – 24V DC
  • Consumption : 5W, Max

Board dimension

• • 130mm x 105mm x 22mm

Mercedes-Benz GLC Backup Camera Features

Features

• • Mercedes Rear-view Camera fitment
  • Flush Mount Camera
  • Vivid Color High Resolution
  • 170° Wide Angle View
  • Parking Guide Lines (can be turned on/off)
  • Waterproof Ip68
  • Shockproof
  • Simple Installation

Specifications

155° Off Axis View Cone

IP69K Waterproof Certified (Can Handle Direct High Pressure Spray and Not Leak)

UV Protected and Waterproof Cabling

0.1 LUX Rating for Optimal Low-light Performance

32° to 160° Temp Performance Rating

Quick Connect/Disconnect

Optional Parking Lines ON/OFF

Optional Mirror Image ON/OFF

Water Deterrent Gasket (Provided for Sealed Mount to Vehicle Surface)

Mercedes-Benz GLC Backup Camera System Package Content

• • Mercedes-Benz Video Interface Module
  • Factory Integrated LCD Cable
  • Factory Integrated LVDS Cable
  • Sub-Board
  • Power Harness
  • AV Harness
  • IR Cable
  • Mode Cable
  • Remote Control
  • Flush Mount Camera
  • Camera Power Harness
  • Camera RCA Extension Cable
  • Camera Screw Set
  • Installation Guide


Please note package content may differ depending on vehicle year and camera option.
