A5 / S5 / RS5 OEM Integrated Backup Camera System

The FC-AUDI-INT/EXT systems package is a high definition rear view camera and video integration module for your vehicle with or without MMI Navigation. The video interface connects through a simple plug and play OEM Integrated LVDS connection to the factory screen. The FC-AUDI-INT/EXT Interface Module has a dedicated rear view camera input that will automatically trigger when in reverse and revert back when in park or drive all using your OEM screen to display the backup camera feed. Along with a dedicated rear camera input, the FC-AUDI-INT/EXT system also has 3 additional AV inputs should you decide to add a front camera (manual trigger), DVD Player, TV Tuner or any external video source with AV inputs. This system is an OEM integration package that maintains your factory set up while upgrading your vehicle with full Multimedia Video Integration. Once installed, the system is ready for use without any dealer activation or coding required.

A5 / S5 / RS5 Systems Compatibility

Model	Model Year	Multimedia System
A5 / S5 / RS5	2008-2015	without MMI (INT)

Model	Model Year	Multimedia System
A5 / S5 / RS5	2009-2016	with 3G MMI (EXT)

AMI vs 3G MMI

How do I know which command system to select? We’ve got you covered. We want to locate the Audi control knob. The location of the Audi control knob will tell us if you have the AMI / Internal MMI system or the 3G MMI / External MMI system.

If your Audi control knob is located in the radio as shown below, you’ll need to select the option that reads “AMI / Internal MMI” upon checkout to receive the compatible system.

If your Audi control knob is located under the shift knob as shown below, you’ll need to select the option that reads “3G MMI / External MMI” upon checkout to receive the compatible system.

Audi EXT MMI Command System

A5 / S5 / RS5 Interface Module Features

Input

- Plug & Play installation by LVDS cable
- 1 x Dedicated Rear-View Camera input
- 3 x A/V Inputs
- 1 x LCD input

Output

- 3 x Audio output
- 1 x LCD output
- Factory button function & provided remote control

Power

- Input power : 8V DC – 24V DC
- Consumption : 12W, Max

Board dimension

- 130mm x 105mm x 22mm

A5 / S5 / RS5 Flush Mount Backup Camera Features

Features

- OEM Style Backup Camera
- Vivid Color High Resolution
- 170° Wide Angle View
- Parking Guide Lines Option (ON / OFF)
- Waterproof Ip68
- Shockproof
- Simple Installation

Features

- Tailgate Handle Camera Fitment
- Trunk Latch Soft Pad Trigger
- Lens Built In
- Vivid Color – High Resolution 720p
- 170° Wide Angle Lens
- Parking Guideline Switcher (ON / OFF)
- Shockproof
- Simple Installation
- No Drilling or Cutting Required
- Waterproof Ip68

For compatibility, please make sure your current tailgate latch measures roughly 4 1/2 inches across

Specifications

155° Off Axis View Cone
IP69K Waterproof Certified (Can Handle Direct High Pressure Spray and Not Leak)
UV Protected and Waterproof Cabling
0.1 LUX Rating for Optimal Low-light Performance
32° to 160° Temp Performance Rating
Quick Connect/Disconnect
Optional Parking Lines ON/OFF
Optional Mirror Image ON/OFF
Water Deterrent Gasket (Provided for Sealed Mount to Vehicle Surface)
